TrueAudio Duplicators

TrueAudio 11 Target CD DVD Duplicator

- Supports CD Audio Disc Comparison

P/N: TrueAudio-S11T-BK

In Stock

2 Years Limited

Free Shipping

~~$1,135.00~~ $905.00

20% Off

TrueAudio 11 Target CD DVD Duplicator

- Supports CD Audio Disc Comparison

P/N: TrueAudio-S11T-BK

In Stock

2 Years Limited

Free Shipping

~~$1,135.00~~ $905.00

Hard Drive Selection:

Optional USB Device:

Rapid Exchange Warranty

Extended Warranty

Copy Protection Dongle:

Introducing the high powered, standalone, optical, TrueAudio CD/DVD duplicator. Vinpower has created their exclusive line of TrueAudio duplication equipment that can perform the 1st ever true Copy and Compare feature for audio CD-R’s. This option will allow operators performing audio CD duplication the assurance that the copied discs will be an exact reproduction of the master content.

The problem with CD duplication towers prior to the TrueAudio series is that there was no way to perform a proper compare after the content was duplicated because CD-R’s had no ECC and there was no way to perform an accurate parity check through the duplicators. That meant there was no way to make an exact 100% recreation of CD audio content. That was until now.

The TrueAudio CD/DVD duplicator is not only the most advanced option on the market, but is extremely simple to use. With the ability to copy all CD configurations, perform the 1st ever accurate compare function of CD-R audio, as well as copy all DVD configurations including Dual/Double Layer discs, the SharkCopier is the perfect solution for your duplication needs. The easy to operate control panel offers many advanced features. Beyond the attractive look of this powerful duplicator, the aluminum casing provides the highest protection against heat and dust, two of the most dangerous elements for a duplicator. This allows the unit to provide optimal performance for an extended period of time.

Complete Standalone Operation: No PC required to operate the duplicator
TrueAudio Copy & Compare Feature: Able to perform the 1st 100% accurate copy plus compare for audio content on CD-R for an exact and verifiably reliable duplication of audio content.
Copy Protection (optional): Able to create copy protected DVD Video copies from an original master using the Copy Connect feature. Transfer image files with the embedded protection directly from a PC to the duplicator's internal HDD.
FREE Copy Protection: Able to create FREE copy protected DVD Video copies using PlexDisc DVD-R from an original master.
Improved Load and Copy Supported (Hard Drive Required): Improved "Load and Copy" to make duplication from Hard Drive faster than ever by simultaneously copy into the blank media while Loading to the hard drive
Continuous Hard Drive Partitioning (Hard Drive Required): The HDD partitions are created without limitations using the same amount of space as the actual content size on the disc. No longer do you have to worry about loosing valuable HDD capacity because your duplicator allocates the exact space required without wasting space like standard partitions on other controllers.
Supports all common CD Formats with Additional Special format including CD-TEXT, ISRC, Over-Burned CD.
Keeps the duplicator functioning optimally.
Improved Drive firmware upgradeability: Capable of upgrading the drives for selected brands through the Duplicator.
Improved Multi-Language capability: The text on the LCD screen can be displayed in English, Spanish, French, Japanese & more. Chinese can be added upon request.
AutoCopy feature: Fast duplication without pressing any buttons.
Account management (password protection): This function will authorize only specific user(s) to operate the duplicator with their preferred settings. Able to assign numerous passwords for multiple users.
Auto-Counter Technology: Displays the total number of discs successfully copied compared to desired output for each project.
Hard Drive Partition/Image Name Editing (Hard Drive Required): Simply stated you can name the images stored on the hard drive partitions.
User friendly interface with 'easy-to-read' LCD display: Offers easy to recognize and use terms and operations on the LCD display for simple usage.
Aluminum Case used to provide a highly functional and attractive exterior.
Fast Key feature: 4 fast keys for faster operations.
Power on Self diagnostics: Keeps the duplicator functioning optimally.
Disc Info feature: Provides the format of the disc & the disc manufacturer's information.
Selectable CD and DVD burning speeds: Ability to increase or decrease duplication speed for supported formats.
Creates mix compilation audio CD: Able to compile multiple tracks onto a single disc from multiple sources.
Supports all currently available DVD media including Double/Dual layer DVD9: Can duplicate Single Layer DVD+-R/RW and Double/Dual Layer DVD±R Formats.
Auto DVD Format Conversion: Can convert media between DVD+R/RW and DVD-R/RW automatically.
Supports both Disk-at-Once and Track-at-Once modes
Automatic format recognition: Duplicator recognizes automatically if the discs are CD or DVD as well as the correct format to copy.
Upgradeable for future drive technology: Able to upgrade duplicator for installation of future drives.
Future functions upgradeable through firmware: Duplicator able to upgrade future software updates via Firmware.
Continuous copying without waiting for cool down: No need to stop the duplicator for fear of overheating.
Optional External USB 2.0 / USB 3.0 connection: Able to connect specific drives to a computer to generate a master disc for duplication.

Model:

TrueAudio 11 Target CD DVD Duplicator

MPN:

TrueAudio-S11T-BK

Operating Type:

Stand-alone

Targets:

Buffer Memory:

128MB

Account Management:

32 users (Standard License) or 64 users (Premium License)

Partition Naming:

Up to 14 Characters Per Partition

Internal Interface:

SATA

Auto Counter:

Yes

Language Support:

English, Spanish, French, German, Italian, Japanese, and more
(Chinese can be ordered on request)

Display:

20 x 2 LCD

Hard Drive:

2 TB (Capable of selecting higher capacity HDD)

Featuring Reader:

Vinpower DVD-ROM

Featuring Recorder:

24x SATA Drive DVD/CD Writer

Maximum Write Speed:

DVD-R: 24x	DVD-RW: 6x
DVD+R: 24x	DVD+RW: 8x
DVD-R DL: 12x	DVD+R DL: 8x
CD-R: 48x	CD-RW: 32x

Formats Supported

DVD-ROM, DVD-Video, DVD-Audio
DVD-R, DVD-RW, DVD+R, DVD+RW
DVD+R Double Layer, DVD-R Dual Layer ,
CD-ROM (Mode1 & Mode2)
CD-ROM/XA (Mode2 form1 & form2)
CD-DA, Mixed-Mode
Video CD, CD-I, Karaoke CD(VCD)
Photo CD (Single & Multi-session)
CD-Extra, HFS, CD-Brid
ISO9660, CD-R, CD-RW
Business Card CD-R, 3" Mini CD-R

Firmware Upgradable:

Yes

Burn Proof Support:

Yes

Physical Size:

Width 7.5" x Depth 21 " x Height 25 "
Weight 32 lbs

Power Supply:

Input : 90 ~ 240 V

Operating Humidity:

20% ~ 80%

Temperature Extremes:

40^oC (104^oF) / 5^oC (41^oF)

Regulation:

FCC, CE, RoHS

Manufacture:

Vinpower Digital

Throughput Capacity Per Hour:

Target	1	2	3	4	5	6	7	8	9	10	11	12	13	14	15
350 MB CD *at 48x duplication speed	24	48	72	96	120	144	168	192	216	240	264	288	312	336	360
2.5 GB DVD *at 16x duplication speed	12	24	36	48	60	72	84	96	108	120	132	144	156	168	180

Important Notice

Optional USB or USB and Firewire combo device is available.

The duplicator will not copy any copy protected discs.

The actual maximum writing speed may vary. Blank media writing speed is determined by the drives, regardless of what the media manufacturer certifies the blank media writing speed at.

Enhanced Load and Copy Supported:
For better efficiency and the best duplication quality. Enhanced Load & Copy is a way to load the master disc on to the Hard Drive while simultaneously copying on to the blank media in the writer drives at the same time for the first run. All other copies will be created from the hard drive for the highest quality. This will greatly speed up the duplication process. It works as shown in the below diagram:

More Synchronous Loading...

Added Shipping Protection:
All duplicators are double packed as shown below with twice as much thick packing foam and cardboard.

A) Strong cardboard outer box to protect the interior box with the duplicator.
B) Interior box for the duplicator which is stored inside protective foam and boxed in sturdy cardboard.
C) Two separate interior supports for the inside box which are made of thick sturdy cardboard and 5 large dense foam supports.

More packing information..

About Copy Protection
Vinpower Digital has developed the first true standalone duplicator which can offer embedded copy protection. The unique CopyLock Software can embed a proprietary CPS copy protection encryption into any DVD video master through a PC, which will produce a VCP or OCP protected image file. The VCP or OCP protected image file can then be transferred onto a CPS enabled Vinpower Digital duplicator to produce as many copy protected reproductions as the user needs. Since the CPS technology is software based as opposed to hardware based, there are no issues with compatibility with players, unlike competing protections on the market. In addition, the CPS technology offers the same secure protection against unauthorized duplication and ripping for a double dose of protection whereas similar applications from competitors cannot block ripping.

The difference between the VCP and OCP formats is that the VCP requires a license dongle in order to add the protection onto the discs and the OCP does not require any licenses as long as true OptoDisc MID media are used during the duplication process. So the VCP has an added cost, but allows you to use any media you'd like and the OCP has no added costs as long as you use OptoDisc manufactured media.

In today's savvy hi-tech world, consumers are often purchasing a single video and making copies for their friends which limit the overall sales. If you worked hard and put in a lot of effort and expense into creating your video project, you shouldn't be restricted in the number of units you can sell because you can't afford the high price of replicated copy protection. Instead, by using Vinpower Digital's CPS technology, you can feel secure at a fraction of the expense with the VCP format or FREE with the OCP format in less time with no minimum or maximum quantities required.

Flow Chart:
CopyProtection Flow Chart

How the FREE OCP Copy Protection Works:

Load the supplied CopyLock software onto a suitable PC.
Take your DVD video master disc or file and use the copy protection software application to make an OCP master image file; follow the steps of the software to embed the copy protection onto the master content.
Transfer OCP file through 1 of the 2 options below:
- Burn the OCP file onto a master disc
- Transfer the new OCP image file from the PC onto an enabled duplicator via USB w/ CopyConnect or LAN/Networkconnectivity if available
Load blank DVD recordable discs with the OptoDisc MID into the duplicator's writer drive(s) then place the OCP master disc into the top reader tray or
locate the transferred OCP image file through the duplicator's menu keys from the internal hard drive if available
Initiate the copy process and when the finished discs are all successfully copied, these discs will have the secure copy protection already embedded.

How the VCP Format Copy Protection Works:

Load the supplied CopyLock software onto a suitable PC.
Plug in the CPS USB dongle with activated licenses into your PC's USB socket.
Take your DVD video master disc or file and by utilizing the special CPS application, follow the steps to embed the copy protection onto the master content.
Transfer VCP file through 1 of the 2 options below:
- Burn the VCP file onto a master disc
- Transfer the new VCP image file from the PC onto an enabled duplicator via USB w/ CopyConnect or LAN/Networkconnectivity if available.
Load blank DVD recordable discs into the duplicator's writer drive(s) then then place the VCP master disc into the top reader tray or locate the transferred VCP image file through the duplicator's menu keys from the internal hard drive if available.
Initiate the copy process and when the finished discs are all successfully copied, these discs will have the secure copy protection already embedded.
